Cometech QC-807 Film Bar Cutter | Tape, Film & Paper Specimen Preparation, 1" Width, 0.05–1 mm, 4 Blades
- Manual bar specimen cutter for preparing long-strip specimens from tape, film, plastic sheet, paper, and similar thin sheet materials for adhesion and peel testing.
- Standard cut width: 1 inch (custom widths available on specification); cutting thickness range: 0.05–1 mm (based on material dimensions).
- Includes 4 replacement blades; lightweight at approximately 250 g, no power required.
- Used as a specimen-preparation step before tape holding power tests (QC-801/802), peel tests, and adhesion tests.
Interested?
Request a quote for this product
Overview
Cometech QC-807 Film Bar Cutter is a manual specimen-preparation tool designed for cutting parallel, straight-edged bar specimens from tape, film, plastic sheet, paper, and similar thin sheet materials.
It is used as a preparatory step before tape adhesion, holding power (QC-801/802), and peel testing workflows to ensure consistent specimen width and clean cut edges.
The standard cut width is 1 inch per most tape test standards; custom widths can be specified at the time of order.
Full Specifications
| Model | QC-807 |
|---|---|
| Specimen width | 1 inch or indicated (custom) width |
| Cutting thickness | 0.05–1 mm (based on material dimensions) |
| Suitable materials | Paper, plastic sheet, film, etc. |
| Cutting method | Manual cutting; suitable for bar specimens |
| Accessory | 4 blades included |
| Weight | Approximately 250 g |
| Power | Not required |
Related products (as listed by Cometech)
- QC-801 Tape Holding Power Tester (Normal Type)
- QC-802 Tape Holding Power Tester (Oven Type)
- QC-803A Manual Roller
- QC-803K Motor Roller
- QC-508M1 Computerized Material Testing Machine (Peeling Tester)
Support materials
- Test video, teaching material, SOP, and test case (availability depends on configuration and region).
