Cometech QC-309D Motor Twist Counter for Yarn | 50–1500 RPM, Auto + Manual Modes, USB Data Output
- Motorized twist counter for determining yarn twist by detecting yarn length/position change during untwisting/twisting.
- F1C controller with built-in pretension reference data to suggest loads for different yarn types.
- Real-time display during testing plus data storage (up to 50 records) and USB output for analysis/reporting.
- Auto mode for single yarn; multi-ply yarns tested in manual mode (pin method).
Interested?
Request a quote for this product
Overview
Cometech QC-309D Motor Twist Counter for Yarn measures twist based on the principle that yarn length changes as twist is added/removed.
A pointer or sensor detects yarn change and the instrument calculates the twist value, which is an important reference for textile process control and QC.
The machine uses an F1C controller, provides pretension recommendations for different yarns, and shows real-time test information on-screen for better control and post-test statistical analysis.
For high-twist yarns, the machine can reduce speed before the test begins to improve measurement precision.
Applications
- Textile labs and production QC: twist control for yarn consistency and process troubleshooting.
- Incoming inspection / supplier verification: confirm twist levels against internal specs or required standards.
- R&D: evaluate how twist affects strength, handle, appearance, and downstream processing performance.
Test Notes (Important)
- Auto mode is suitable only for single yarn.
- Two-fold or multi-ply yarns should be tested in manual mode using the pin method.
- If the yarn has elasticity, provide a sample for pre-test to confirm the correct setup/conditions.
Technical Specifications
Standards (as listed)
- ISO 2061
- ASTM D1422 / ASTM D1423
- BS-903 / BS 2085
- FZ-T10001
- JIS L1095
Core specifications
| Model | QC-309D |
|---|---|
| Display | 7” TFT digital display |
| Rotation speed | 50–1500 RPM (adjustable) |
| Twist direction | S or Z (switchable) |
| Test modes | Semi-automatic, Full-automation |
| Data handling | Store up to 50 records; output test data via USB |
| Clamp distance range | 5–52 cm |
| Common clamp distances | 10” (25.4 cm) and 20” (50.8 cm) or as indicated |
| Pretension weights set | 0.3 g, 0.5 g, 0.8 g, 1 g, 2 g, 3 g, 5 g (each 1 set), 10 g (2 sets) |
| Pretension (listed) | 1.2 g |
| Power supply | Single phase 100–240 V |
| Dimensions (W × D × H) | 97 × 20 × 32 cm |
| Machine weight | 13.6 kg |
| Industry | Textile |
